| Item | SINOTRUK HOWO DUMP TRUCK 6x4 |
| Truck model | ZZ3257M3247W/ZZ3257N3647A |
| Max driving speed: | 50km/h |
| Engine model | 290/336HP, EURO II |
| Carriage internal size: | 4100/4200/4800/5100/5200*2300*800*1200/1350/mm;volume:13-15m3 Thickness: bottom 8/10/12mm, sides: 4/6/8/10mm |
| Front Axles | HF12, 12000KG |
| Rear Axles | HC16, 16000kg |
| Steering | ZF8098, GERMANY |
| Tires | 12.00R20 Radial tire Option: nylon tire |
| Air conditioner | With safety belts for driver and co-driver |
| Transmission | HW15710/ HW19710, 10F&2R |
| Export Markets | South America, Southeast Asia, Africa, Mid East, Eastern Asia |
| Loading Capacity | 8-20t |
| Driver's Cab | No sleeper/one sleeper/ two sleepers, VOLVO TECHNOLOGY |
| Hydraulic Lift of Carriage | T model (ventral lift)/ front lift |
| No. | Main Spare Parts recommendation | Quantity |
| 1 | Fuel filter | 3 |
| 2 | Lubricating oil filter | 3 |
| 3 | Air cleaner | 3 |
| 4 | Clutch plate | 1 |
| 5 | Brake disk set(front) | 2 |
| | Brake disk set(rear) | 2 |
| 6 | Fan belt | 1 |
| 7 | Air condition belt | 1 |
| 8 | Relay | 1 |
| 9 | Release bearing(inner and outer) | 1 |
| 10 | Seal kit for hub(rear and front) | 1 |
| 11 | Seal kit for differential pinion(front and rear) | 1 |
| 12 | Cross joint for transmission-front differential | 1 |
Description:
SINOTRUK Kogel Special Truck Co., Ltd. are located in Jinan Industrial Development Park, that engaged in developing and manufacturing special truck and components, the modern professional enterprise is a public announcement management company of the Ministry of Industry and Information and is a major transportation equipment manufacturing enterprise in Jinan City.
1.Sinotruk dump truck adopt many key technologies both from home and abroad, and it can achieve the best design and be in good conditions.
2.Low oil consumption. Sinotruk adopt the engine that combine the MAN and technolgoy, it has the perfect oil performance.
Applications:
It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials.
Competitive Advantage
1. superior carrying capacity
2. Starting ability good with heavy load
3. High speed
4. fuel economy
5. Comfortable and cab
6. Light curb weight
7. High quality
8. Good performance with low price
